MMA ADHESIVE
ADINOX® M330 Methacrylate Adhesive for Galvanized Steel
Two-Part 1:1 Toughened Structural Adhesive for Zinc-Coated Metals
Available sizes
50 ml
Dual cartridge 1:1
400 ml
Dual cartridge 1:1
5 gal
Pail
About ADINOX M330 Methacrylate Adhesive for Galvanized Steel
ADINOX® M330 is a methacrylate adhesive for galvanized steel — an advanced, two-part (1:1) toughened structural adhesive designed for high-strength bonding of various metals, with exceptional performance on galvanized (G60, G70, G90) and zinc-coated metals.
This high strength methacrylate adhesive delivers excellent toughness, fatigue and impact resistance with a low odor profile, and bonds most reference surfaces with minimal to no surface preparation. It is available with or without glass bead spacers for uniform bond-line thickness.
Glass Bead Structural Adhesive - 1:1 Mix Ratio
- Available with or without glass bead spacers for uniform bond-line thickness
- Gap filling up to 0.29 in for irregular joints and oversized bond lines
- Convenient 1:1 mix ratio by volume and weight - room temperature cure
- Open time 4 - 6 minutes - working time 10 - 12 minutes
High Strength Methacrylate Adhesive - Toughened & Low Odor
- Tensile strength: 3,191 - 3,771 PSI (ASTM D 638)
- Lap shear >2,321 PSI on steel, stainless steel and aluminum - cohesive failure
- Excellent fatigue toughness and impact resistance with low odor
- Retains >2,900 PSI after 30-day immersion in gasoline, xylene and hot water
- Gains strength after 30-day environmental cycling (>3,481 PSI)
Direct Adhesion on Galvanized and Zinc-Coated Metals
- Evaluated on G60, G70 and G90 galvanized grades
- Lap shear >1,886 PSI on galvanized metal (G70) - cohesive failure
- The methacrylate adhesive for galvanized steel that requires minimal to no surface preparation
- Ideal for galvanized structures, HVAC ductwork and coated sheet-metal assemblies
Technical Information
Uncured (liquid) properties
Appearance - Resin A / Activator B | White / Gray |
Viscosity A (77°F) | 63,000 - 132,000 cP |
Viscosity B (77°F) | 45,000 - 110,000 cP |
Density A / B / Mixed | 8.2 / 8.0 / 8.1 lbs/gal |
Mix ratio (volume / weight) | 1:1 / 1:1 |
Flash Point | 51°F |
Mixed / cured color | Gray / White-Green |
Cured Product Properties
Open time / Working time | 4 - 6 min / 10 - 12 min |
Full cure | 24 hours @ 77°F |
Gap filling | Up to 0.29 in |
Hardness Shore D (ASTM D 2240) | 71 - 74 |
Elongation (ASTM D 638) | 22 - 28% |
Tensile modulus (ASTM D 638) | 75,000 - 100,000 PSI |
Tensile strength (ASTM D 638) | 3,191 - 3,771 PSI |
Service temperature | -40 to 180°F |
Lap Shear Strength by Substrate (ASTM D 1002)
Substrate | Strength | Failure Mode |
Steel & stainless steel | >2,321 PSI | Cohesive failure |
Aluminum / aluminum | >2,321 PSI | Cohesive failure |
Galvanized metal (G70) | >1,886 PSI | Cohesive failure |
Temperature Resistance - Al/Al (ASTM D 1002)
Temperature | Strength |
-40°F | >5,221 PSI |
25°F | >4,786 PSI |
77°F | >3,191 PSI |
180°F | >2,466 PSI |
Environmental Aging - Al/Al (ASTM D 1002)
Initial | >3,191 PSI - cohesive failure |
After 30-day cycle | >3,481 PSI - cohesive failure |
Cycle: 8 h at -22°F / 8 h at 185°F / 8 h at 86°F at 100% relative humidity.
Chemical Resistance - Al/Al, 30-Day Immersion (ASTM D 1002)
Medium | Retained Strength |
Gasoline | >3,191 PSI |
Acetic acid 10% | >3,191 PSI |
Xylene | >3,191 PSI |
Lubricating oil HD-30 | >3,336 PSI |
Kerosene | >3,191 PSI |
Water at 73°F | >3,046 PSI |
Water at 194°F | >2,901 PSI |
Cleavage Peel Strength - SS/SS (ASTM D 3807)
Initial peel strength | >18 pli |
Average peel strength | >17 pli |
How to Use ADINOX M330?
Surface Preparation
- Wear gloves and protective eyewear - work in a well-ventilated area
- Surfaces must be clean, dry and free of dust, grease and oil
- Degrease with ADINOX® DS 400 - clean mechanically or chemically if needed, then dry completely
Prepare the Adhesive
- Purge a small amount of each component without the mixing nozzle
- Attach the 1:1 mixing nozzle securely and insert the cartridge into the application gun
- Purge again with the nozzle installed, then apply a continuous, uniform bead without stopping
Bond and Cure
- Join parts within the 4 - 6 min open time - apply constant, uniform pressure
- After the 10 - 12 min working time (~70% cure), do not move the parts
- Full cure in 24 h at 77°F - remove the nozzle and clean the cartridge outlet horizontally
Get the ADINOX M330 methacrylate adhesive for galvanized steel through our authorized distributor network, in two dual-cartridge sizes and 5 gal pails.
Join our distributor network and offer your customers high strength methacrylate adhesive solutions for galvanized and coated sheet-metal bonding programs.
Become a Partner
Where to Buy?
If you are using ADINOX M330, you may be interested in
ADINOX® DS 400
Industrial Degreaser
Cleans and degreases substrates before bonding. Recommended surface preparation for M330.
Caulking Guns
1:1 Dispensing Equipment
Manual and pneumatic guns for 1:1 dual cartridges. Required for M330 application.
Mixing Nozzles
Static Mixers 1:1
Ensure a homogeneous 1:1 mix of both components. Essential companion for M330.
Frequently Asked Questions
What is the ADINOX M330 methacrylate adhesive for galvanized steel?
ADINOX M330 is a methacrylate adhesive for galvanized steel: an advanced, two-component (1:1) toughened structural adhesive for high-strength bonding of metals, with exceptional performance on galvanized and zinc-coated surfaces.
Can M330 bond galvanized and zinc-coated metal?
Yes. M330 has been evaluated on G60, G70 and G90 galvanized grades, achieving lap shear above 1,886 PSI with cohesive failure. Because coatings vary in thickness, treatment and passivation, users should verify performance on their specific substrate.
What is the mix ratio of M330?
M330 uses a 1:1 mix ratio by volume and by weight, dispensed through a static mixing nozzle from a dual cartridge, with a 4-6 minute open time and 10-12 minute working time.
How strong is M330?
As a high strength methacrylate adhesive, M330 delivers tensile strength of 3,191-3,771 PSI (ASTM D 638) and lap shear above 2,321 PSI on steel, stainless steel and aluminum, with cohesive failure.
What gap can M330 fill?
M330 fills gaps up to 0.29 in and is available with glass bead spacers — making it a glass bead structural adhesive option for uniform bond-line thickness on irregular joints.
What is the service temperature range?
This methacrylate adhesive for galvanized steel performs from -40 to 180°F when cured, retaining cohesive failure performance across the range.
Does M330 need surface preparation?
This methacrylate adhesive for galvanized steel requires minimal to no preparation — surfaces only need to be clean, dry and free of grease or oil. For demanding applications, degrease with ADINOX DS 400.
How does this methacrylate adhesive for galvanized steel compare to other 1:1 systems?
M330 combines a convenient 1:1 mix ratio with toughened, low-odor chemistry and proven adhesion to galvanized metal, offering a direct alternative for zinc-coated and coated sheet-metal bonding programs.
Is M330 resistant to chemicals and weathering?
Yes. After 30-day immersion (ASTM D 1002, Al/Al), M330 retains over 2,900 PSI against gasoline, xylene, 10% acetic acid, HD-30 oil, kerosene and hot water, and gains strength after the 30-day environmental cycle.
