ADINOX M420
Available sizes
About M420
ADINOX M420 is a flexible, two-part methacrylate adhesive designed for the structural bonding of various materials, including fibreglass and certain plastics. It forms strong, flexible bonds with these materials, typically without the need for preparation. ADINOX M420 also bonds steel, stainless steel and other metals, allowing considerable movement of the substrates due to differences in their coefficients of thermal expansion.
With a mixing ratio of 10:1, ADINOX M420 achieves handling strength in 10–15 minutes and 90% of its full strength in 30 minutes at room temperature.
With a mixing ratio of 10:1, ADINOX M420 achieves handling strength in 10–15 minutes and 90% of its full strength in 30 minutes at room temperature.
Technical Information
Mix Ratio
10:1
Color
Amber
Open time
4 to 7 min
Working time
10 to 15 min
Filling capacity
3 mm
Elongation
50%
Tensile strength
2,500 - 3,500 PSI
Operating temperature range
-40 to 250 °F
Hardness
73D
Standard sizes
50 ml, 490 ml, 18 Kg
How to use ADINOX M420?
1. Clean the surface
Clean the surface with isopropyl alcohol.
2. Apply ADINOX
Apply the adhesive in a zigzag pattern on the surface.
3. Bond
Join the 2 substrates and hold them together until they cure.
If you are using ADINOX M420, you may be interested in
Primer
Caulking guns
Mixing nozzles
I have a complicated application and would like to check compatibility
